MILD 7W LOW GLARE LED DOWNLIGHT IP65 front fire rated CCT switchable
Short Description:
CODE：5RS102
●RT2012/RE2020 compatible
●Fire rated certified both i-joist & solid joist ceiling
●Low glare UGR<19
●Interchangeable bezels ( two options: twist & lock or easy fit magnetic bezel )
●3CCT switchable 2700K/3000K/4000K
●Easy and fast wiring for power supply
●IP 65 rated
●Acoustic rated
●Insulation coverable
●5 years warranty
Description
MILD is a 7W 3CCT spotlight which should be suitable for the market much well.
The design of the MILD is aimed at increasing visual comfort, reducing strain and fatigue on the eyes. The combination between the deep set LED chips, anti-glare bezel & high quality reflector construction achieves such higher performance as UGR<19. It hides the light source so that you see the effect but not the light itself and that’s what you get with an anti-glare downlight. So where we would use this type of light fitting? The areas such as perhaps you’ve got a cinema room or a multi-use room so where you’ve got a TV in there, possibly above dining tables where you might be spotlighting the table itself but there where you just don’t get that glare, It is a very subtle light. In addition, the fitting is IP65 and can be installed in any high moisture areas, such as kitchen & bathroom. The function of interchangeable bezels, which greatly saving supplier’s stock and cost, user will have more choices.
We believe that innovation and passion can make the world differently, by managing every detail of our led recessed downlight products. Quality is the first priority in our products, so that each part of our LED downlights are strictly selected and inspected. Product quality and user convenience are the central focus in our LED downlight designing. Besides the quality, convenient and smart designs are needed for fast installation in saving labor time and cost, which brings the best experience to the end users.
Dimensions
Technical Specification of led downlight
|
Item |
3CCT Downlight |
Power Factor |
0.85 |
|
Part No. |
5RS102 |
IP |
IP65 Front |
|
Power |
7W |
Cut Out |
Φ 68mm |
|
CCT |
2700K/3000K/4000k |
Low Galre |
UGR＜19 |
|
Lumen |
500-550 lm |
Dimmable |
- |
|
Input |
AC 220-240v-50HZ |
Size |
Drawing Supplied |
|
CRI |
80 |
LED |
SMD |
|
Beam Angle |
40° |
Switch Cycles |
100,000 |
Application Areas
It is designed for general lighting applications in living room, hall, hotel, office, store, supermarket, shop, school, hotel residence, show room, bathroom, shop window, assembly room, factory, etc.
Lediant Lighting brief introduction
Specialist ODM supplier of LED downlight products
Lediant lighting is a client-focused, professional, and “technology-oriented” leading LED downlight manufacturer since 2005. With 30 R&D staff members, Lediant customizes for your market.
We design and manufacture led downlights suitable for a wide variety of applications. The product range covers domestic downlights, commercial downlights and smart downlights.
All product sold by Lediant is tool opened product and has its own innovation added to the value.
Lediant can offer one stop service from product design, tooling, package design and video creation.
